SINCGARS Power Supply Docking Station
Comms operational in minutes. No assembly required.
The PTS SINCGARS PSDS docks the RT-1523 (E/F) ASIP radio and AM-7238B RF Power Amplifier in fixed and semi-fixed environments — expeditionary command posts, combat operation centers, forward operating bases, tactical and non-tactical vehicles, garrison training ranges, and electronic direct support maintenance facilities. Comms up within minutes of arrival. No assembly, no training required. AC or DC power worldwide.
Use your browser's print dialog to save as PDF.
GSA Schedule
47QSWA22D008V · NAICS 334220
Aug 2022 – Aug 2027
CHS-6 Contract
W15P7T-23-D-0003
Prime: Leidos
DLA SOE/TLSP Contract
SPE7LX-26-D-0050
SINCGARS PSDS Only
GPC accepted
View GSA Schedule pricing on GSA Advantage14,000+
Units fielded worldwide
30
Years of PSDS production
5 min
From unpack to comms
Built for the warfighter. Proven in the field.
PTS developed the original Power Supply Docking Station in 2000 to solve a persistent field problem: getting SINCGARS radios operational quickly in expeditionary environments without the complexity of traditional vehicle mounting systems. More than two decades later, the PSDS is used for training purposes at the U.S. Army Signal Center of Excellence and has been fielded across every Active Army Division.
The PSDS provides regulated, conditioned power to the attached radio from virtually any AC (85–260VAC) or DC (20–33 VDC) power source worldwide, automatically adapting to whatever power is available — generator, vehicle battery, shore power, or solar — with no manual reconfiguration.
Lightweight, ergonomic, and engineered for rapid setup, the PSDS enables Signal personnel to establish communications within minutes of unit arrival. No specialized tools. No lengthy installation procedure. Connect power, dock the radio, establish comms.
Product variants
AS0004-SR-4
Dual radio — AC configuration
- Compatible radio
- RT-1523 (E/F) ASIP
- Compatible amplifier
- AM-7238B RFPA
- Docking capacity
- 2 radios + 2 RFPAs
- Part number
- AS0004-SR-4
- NSN
- 6130-01-618-9824
- AC input
- 85–260 VAC
- Operating temp
- -20°C to 70°C
- Weight
- 19.1 lbs (41.1 lbs with wheeled SKB 3i-2317-14 transit case — case alone is 20.8 lbs)
- Dimensions
- 17.5" x 13.1" x 12.9"
AS0004-SR-4A
Dual radio — AC/DC configuration
- Compatible radio
- RT-1523 (E/F) ASIP
- Compatible amplifier
- AM-7238B RFPA
- Docking capacity
- 2 radios + 2 RFPAs
- Part number
- AS0004-SR-4A
- NSN (Olive Drab)
- 6130-01-578-4483
- NSN (Tan)
- 6130-01-577-7393
- AC input
- 85–260 VAC
- DC input
- 20–33 VDC
- Available colors
- Olive Drab (OD), Tan
- Operating temp
- -20°C to 70°C
- Weight
- 20.1 lbs (42.1 lbs with wheeled SKB 3i-2317-14 transit case — case alone is 20.8 lbs)
- Dimensions
- 17.5" x 13.1" x 12.9"
The AS0004-SR-4A adds DC power input (20–33 VDC) not available on the AS0004-SR-4.
Not sure which model fits your requirement? Contact PTS at 256-539-6787 or info@pts-inc.com.
Key features
Radio docking
Docks RT-1523 (E/F) ASIP radio and AM-7238B RFPA in a single integrated unit.
Dual DC inputs
Two DC voltage inputs accepting 20–33 VDC from vehicle batteries or portable power (AS0004-SR-4A).
Universal AC power
85–260VAC input covers power grids worldwide with no reconfiguration.
Conditioned output
Regulated, conditioned power output protects sensitive radio electronics in field conditions.
5-minute setup
Operational in less than 5 minutes from unpack to comms. No assembly required.
Zero training
No tools, no training required. Designed for immediate use by any military user.
Color options
Available in Olive Drab (OD) and Tan to match operational requirements (AS0004-SR-4A).
COTS design
Commercial Off-The-Shelf product designed and proven for field use in expeditionary environments.
Made in USA
Designed and manufactured in North Alabama, USA. Export-controlled (not ITAR).
Technical specifications — select your model
Scroll up to compare the AS0004-SR-4 and AS0004-SR-4A variants.
| Parameter | Value |
|---|---|
| Compatible Radio | RT-1523 (E/F) ASIP (SINCGARS) |
| Compatible Amplifier | AM-7238B RFPA |
| Radio Docking Capacity | 2 RT-1523 radios |
| Amplifier Docking Capacity | 2 AM-7238B RFPAs |
| DC Input Voltage | 20–33 VDC |
| AC Input Range | 85–260 VAC |
| NSN (Olive Drab) | 6130-01-578-4483 |
| NSN (Tan) | 6130-01-577-7393 |
| Available Colors | Olive Drab (OD), Tan |
| Operating Temperature | -20°C to 70°C |
| Relative Humidity | 5% to 95% |
| Weight (PSDS only) | 20.1 lbs |
| Weight (with case) | 42.1 lbs (incl. 20.8 lb wheeled SKB transit case) |
| Dimensions | 17.5" x 13.1" x 12.9" |
| Includes | Filter pack, power cord, MIL-SPEC transit case |
| Environmental Rating | COTS — suitable for expeditionary field environments |
| Country of Origin | USA (North Alabama) |
| Export Classification | Export-controlled — ECCN 3A611.x |
| Cage Code | 06AE7 |
Where the PSDS performs
Expeditionary Command Post (CP)
Rapid comms establishment with no permanent installation required.
Combat Operation Center (COC)
Reliable conditioned power for sustained ops.
Forward Operating Base (FOB)
Universal power input for generator or battery operation.
Garrison Training Range
Standardized setup for training realism.
Electronic Direct Support Maintenance
Test and maintain radio systems with consistent power.
Tactical & Non-Tactical Vehicles
Install SINCGARS communications in tactical and commercial vehicles without permanent vehicle modification.
Compatible radio configurations
| Designation | Type |
|---|---|
| RT-1523 (E/F) ASIP | SINCGARS |
| AM-7238B | RF Power Amplifier |
Need a docking station for a different radio?
PTS manufactures dedicated PSDS systems for the full range of tactical radio platforms.
How to procure the SINCGARS PSDS
PTS SINCGARS PSDS products are available through multiple procurement channels. US military and government customers can order using NSN numbers via DLA or through the GSA Schedule (MAS contract 47QSWA22D008V). Direct orders from PTS are accepted via Direct Contract or Government Credit Card (GPC/IMPAC) purchase only.
GSA Schedule
Multiple Award Schedule (MAS)
- Contract
- 47QSWA22D008V
- NAICS
- 334220
- Period
- August 30, 2022 – August 29, 2027
Federal, state, and local government agencies can order PTS products directly through GSA Advantage using MAS contract 47QSWA22D008V, NAICS 334220. No separate solicitation required.
Order on GSA AdvantageDLA SOE/TLSP
Special Operational Equipment — Tailored Logistics Support Program
- Contract
- SPE7LX-26-D-0050
PTS products can be ordered through the DLA Troop Support Special Operational Equipment (SOE) Tailored Logistics Support Program using MIPR/MILSTRIP processes. One-time FOPOC registration with DLA is required (SOECustomerRegistration@dla.mil). The SINCGARS PSDS line is also available under direct DLA contract SPE7LX-26-D-0050.
Contact PTSDirect Contract or Credit Card
Direct procurement from PTS is available via Direct Contract or Government Credit Card (GPC/IMPAC card) purchase. Contact PTS to initiate a direct contract or to place a credit card order.
Contact PTSOrdering reference numbers
NSN (SR-4)
6130-01-618-9824
NSN (SR-4A OD)
6130-01-578-4483
NSN (SR-4A Tan)
6130-01-577-7393
Cage Code
06AE7
DLA Contract
SPE7LX-26-D-0050
Frequently asked questions
The PTS SINCGARS PSDS is compatible with the RT-1523 (E/F) ASIP radio and the AM-7238B RF Power Amplifier. Both the AS0004-SR-4 and AS0004-SR-4A dock two radios and two amplifiers simultaneously. For other radio platforms, PTS offers dedicated PSDS models — see the L3Harris, CNR, and RTX product pages.
The AS0004-SR-4A accepts DC input from 20–33 VDC (compatible with standard military vehicle batteries and portable power systems) and AC input from 85–260 VAC — covering power grids worldwide. The AS0004-SR-4 is AC-only (85–260 VAC). Both models adapt automatically to available power with no reconfiguration.
The AS0004-SR-4 has NSN 6130-01-618-9824. The AS0004-SR-4A has NSN 6130-01-578-4483 in Olive Drab and NSN 6130-01-577-7393 in Tan.
The PTS SINCGARS PSDS requires no assembly and no tools. A trained operator can have the radio docked, power connected, and comms established in under 5 minutes from the time the unit is unpacked. No specialized training is required — the system is designed for immediate use by any military user.
No. The PSDS is a standalone ancillary system that enables installation of the SINCGARS radio in fixed and semi-fixed environments — including tactical and non-tactical vehicles — without permanent vehicle modification. It is designed for expeditionary use where rapid setup and teardown are required.
Yes. PTS holds GSA MAS contract 47QSWA22D008V (NAICS 334220) and DLA contract SPE7LX-26-D-0050. Military customers can also order through the DLA Tailored Logistics Support Program using MIPR/MILSTRIP processes. Direct orders are accepted via Direct Contract or Government Credit Card (GPC/IMPAC). PTS Cage Code is 06AE7.
Calculate Your Battery Savings
Eliminate battery dependency entirely using AC or DC shore power.
Your Radio & Deployment
PSDS Model
AS0004-SR-4A-OD
Battery use = radios × 2 batteries/radio/day
Continuous CP ops = 24
NTC = 21 days · deployment = 90–270 days
BB-2590/U: $218.23 (est.) · 2 batteries/radio/day · PSDS GSA: $9252
Your Savings Estimate
Total Battery Cost (this deployment)
$157,126
720 batteries × $218.23
PSDS Investment
$37,008
4 units at $9,252 GSA price
Net Savings This Deployment
$120,118
Estimated savings vs. BB-2590/U over 90 days
Payback Period
21 days
PSDS pays for itself after this many operational days
Estimated Annual Savings
$629,830
Based on 365-day ops, 5-year PSDS service life
Ready to eliminate battery dependency?
PSDS model: AS0004-SR-4A-OD · GSA Contract 47QSWA22D008V · NAICS 334220 · GPC accepted
Estimates based on BB-2590/U (NSN 6140-01-490-4316) at $218.23/unit and a consumption rate of 2 batteries per radio per day under continuous CP operations. PSDS price shown at the current GSA schedule price (47QSWA22D008V catalog). Actual savings depend on operational tempo, procurement vehicle, and local battery pricing. PSDS service life assumed at 5 years for annual savings calculation. PTS Expeditionary Communications makes no warranty as to the accuracy of these estimates for any specific program.
